1959-74 Aluminum Radiator, 2-row

Northern 2 Row Aluminum Radiator - Upper Inlet Driver Side, Lower Outlet Passenger Side

Upgrade your cooling system with this high performance bolt-in radiator from Northern Radiator! Manufactured with race-proven technology, this r adiator is a two-row, 1" core tube design for maximum cooling efficiency.

• Bolt-in installation
• 60% lighter than copper / brass
• Up to 75% more cooling capacity
• All-welded construction with no s older connections
• Heavy duty, die-stamped tanks
• Extra thick hose connections
• Billet filler neck
• 7 plate alumimum transmission cooler

Made in USA

OVERALL DIMENSIONS 29" X 18-1/2" X 3-1/8" (INCLUDES THE RADIATOR, TANKS & BRACKETS)

DIMENSIONS INCLUDING TANKS = 26-1/4" L X 18-1/2" H X 3-1/8" W

CORE DIMENSIONS 22-3/8" L X 17-3/8" H.

USE WITH FAN SHROUD Z40031

Important: Measurements may be needed for applications. Modification to the core support may be required for installation. Will work on both automatic and manual vehicles. Transmission cooling lines may have to be modified.

We also recommmend Part# FL32060 (sold separately) cooling system anode to protect your aluminum radiator.

Note: Shipped overs ize.
