1970 Ford F-100, F-250, F-350 Pickup Truck; Color Wiring Diagram

If you're tired of trying to read and decipher cryptic black and white wiring diagrams out of your old shop manual, this wiring diagram is the solution.

Features

• Complete basic car included (engine bay, interior and exterior lights, under dash harness, starter and ignition circuits, instrumentation, etc)
• Original factory wire colors including tracers when applicable
• Large size, clear text, easy to read
• Laminated for ease of use

• 1970 - 1970 Ford F-100
• 1970 - 1970 Ford F-250
• 1970 - 1970 Ford F-350
